10 Cube Tipper Truck for Sale — Used Chinese 6x4 Dump Trucks

What Does "10 Cube" Mean?

Cube is short for cubic metre. A 10 cube tipper has a steel or aluminium body with an internal volume of 10 m³. It is a measure of how much space the body holds, not how much it weighs. This is different from the GVM or payload rating stamped on the registration papers.

As a rough guide: 10 m³ of dry building sand is around 15 tonnes; 10 m³ of crushed stone is closer to 17 to 18 tonnes. Always match the material density to the truck's rated payload before loading. The body volume tells you how full you can fill it; the axle ratings tell you how heavy you can go.

In East Africa and the Middle East, buyers sometimes refer to the same size as a 10m3 tipper or a 10 cubic metre tipper. These are the same thing.

Why 10 Cube Is the Standard Construction Tipper

The 10 m³ body sits on a 6x4 chassis — three axles, two of which are driven. This combination gives enough payload capacity for bulk earthworks and aggregate delivery without requiring a super-heavy haulage licence in most Southern and East African jurisdictions. It is the standard spec for plant hire fleets, road contractors, housing developers and quarry operators.

Smaller bodies (6 cube, 8 cube) are lighter and easier to manoeuvre on congested urban sites. Larger bodies (14 cube, 16 cube) carry more per trip but cost more to operate and are restricted on certain roads. The 10 cube sits in the middle: enough volume for meaningful productivity, common enough that spare parts and drivers are easy to find.

For most buyers running general construction, sand supply or stone delivery in Africa, the 10 cube tipper is the one that pencils out best.

Payload-to-Body Ratio: Getting the Most from 10 m³

Body volume and payload rating are two separate limits, and the one that bites first depends on the material. A 10 m³ body on a typical HOWO 6x4 with a 20–25 tonne rated payload will run out of volume before weight when hauling dry topsoil (density ~1.2 t/m³, so the body fills at roughly 12 tonnes — well within the axle limits). Switch to wet crusher run at 1.8 t/m³ and the same body holds 18 tonnes — now you are close to the payload ceiling and the body is not even full.

Experienced operators know this and adjust loading accordingly. For dense aggregates, they load to a set mark on the body sides rather than filling to the rim. For lighter material, they heap above the rim to maximise volume per trip. The 10 m³ body is popular precisely because it sits at the balance point: large enough to be productive on light material, strong enough on a 6x4 chassis to handle dense loads without chronic overloading.

Who Buys a 10 Cube Dump Truck?

The buyers Sigma works with most often are:

• Building contractors: moving sand, stone, fill and spoil on housing and commercial projects.
• Plant hire companies: renting tippers to contractors by the day or month — a 10 cube is the size most customers ask for.
• Quarry and aggregate suppliers: running fixed routes from quarry face to delivery point.
• Road construction crews: carrying base course, sub-base material and gravel on rural road projects across East and Southern Africa.
• Government and NGO infrastructure programmes: procuring a small fleet for a specific road or housing tender.

Most of these buyers need LHD (left-hand drive) for West Africa and the Middle East, or RHD (right-hand drive) for South Africa, Zimbabwe, Zambia, Kenya, Uganda and Tanzania. Sigma converts in-house to either configuration before shipping.

10 Cube vs Other Tipper Sizes — Quick Comparison

• 6 cube tipper (6 m³): Lighter, often on a 4x2 or smaller 6x4 chassis. Suitable for urban delivery, tight sites, softer roads. Lower payload, lower cost. See our 6 cube tipper truck for sale page.
• 10 cube tipper (10 m³): The standard 6x4 construction size. Best balance of payload, road access and operating cost. Most common in Southern and East Africa.
• 14–16 cube tipper (14–16 m³): Higher volume per trip, suited to high-output quarry or earthworks operations. Heavier chassis, higher fuel cost, needs better roads.

If you are unsure which size suits your operation, send us the material type, average haul distance and road conditions. We will advise the right spec.

Loading and Tipping Cycle Times on a 10 Cube Tipper

Cycle time — the minutes from arriving empty at the loading point to tipping and returning empty — is what determines daily output. On a 10 m³ tipper, the key time segments are:

• Loading: A 20-tonne excavator fills a 10 m³ body in 3–5 bucket passes, taking roughly 2–4 minutes depending on material and operator skill. Front-end loaders take longer — 4–6 passes, 5–8 minutes.
• Haul (loaded): Varies entirely by distance and road condition. A 10 km sealed-road haul might take 15 minutes; the same distance on a rutted laterite track could take 30.
• Tipping: Hydraulic raise on a HOWO or SHACMAN 6x4 body takes 15–25 seconds. Sticky clay or wet soil may need a few body shakes to clear — add another 30 seconds.
• Return (empty): Faster than loaded. Same 10 km run in 10–12 minutes on a good road.

On a realistic 10 km round trip with good loading, a single 10 cube tipper can manage 8–12 loads per day. Fleet operators use this number to size their truck count against the excavator output — one excavator can typically keep 3–4 tippers running without idle time.
